Description:
Zinc anode is a kind of zinc component used to help galvanized steel and other objects. It is often used to prevent corrosion and help other materials corrode more slowly and last longer. The sacrificial zinc anode is also a part of a large system which gives objects corrosion resistant abilities. They are common among metallic marine applications, such as boats with metal hulls and metal crab pots. Saltwater is very corrosive and will quickly rust the metal, unless the galvanic coupling (voltaic couple) is formed with the sacrificial zinc anode, which can greatly increasing its useful life in the water. Zinc anode has been developed in CORROCO for more than 10 years. With high capacity, current efficiency and high machine performance, sacrificial zinc anodes are widely used in cathodic protection of tank bottom, pipeline, and water pipe in soil environments.
Chemical Compositions of Cast Zinc Anode:
Chemical Composition:
|
|
|
TYPE I
|
TYPE II
|
|
Aluminium (Al)
|
0.1 - 0.5%
|
0.005% max.
|
|
Cadmium (Cd)
|
0.02 - 0.07%
|
0.003% max.
|
|
Iron (Fe)
|
0.005% max.
|
0.001% max.
|
|
Lead (Pb)
|
0.006% max.
|
0.003% max.
|
|
Copper (Cu)
|
0.005% max.
|
0.002% max.
|
|
Zinc (Zn)
|
balance
|
balance
|
Electrochemical Properties of Sacrificial Zinc Anode:
Electrochemistry Capability:
|
|
TYPE I
|
TYPE II
|
|
Open - Circuit Voltage (-V) :
|
1.05
|
1.10
|
|
Closed - Circuit Voltage (-V) :
|
1.00
|
1.05
|
|
Actually Capability (A.h/lb):
|
≥ 353
|
≥ 335
|
|
Efficiency:
|
≥ 95%
|
≥ 90%
|
Parameters of Zinc Anode:
Zn Anode for Tank:
Model
|
Dimension
L× (Top Width + Bottom Width) × H
|
Weight
KG
|
|
CZT-1
|
500×(115+130)×130
|
56
|
|
CZT-2
|
800 ×(56+74)×65
|
25
|
|
CZT-3
|
800 ×(58+64)×60
|
22
|
|
CZT-4
|
250 ×(80+100)×85
|
13
|
|
CZT-5
|
200 ×(70+90)×7
|
7.5
|
Zn Anode for Hull:
Model
|
Dimension
L × W × H
(mm
)
|
Weight
KG
|
|
CZH-1
|
800 ×140 ×57
|
40
|
|
CZH-2
|
800×140 ×40
|
30
|
|
CZH-3
|
600 ×120 ×50
|
24
|
|
CZH-4
|
500 ×100 ×40
|
14
|
|
CZH-5
|
400 ×100 ×40
|
10
|
|
CZH-6
|
300 ×100 ×40
|
8
|
|
CZH-7
|
300 ×150 ×40
|
12
|
|
CZH-8
|
390 ×120 ×50
|
16
|
Zn Anode for Dock and Offshore Projects:
Model
|
Dimension
L× (Top Width + Bottom Width)× H
|
Weight
KG
|
|
CZD-1
|
1000 ×(115+135)×130
|
122
|
|
CZD-2
|
750 ×(115+135)×130
|
90
|
|
CZD-3
|
500 ×(115+135)×130
|
61
|
|
CZD-4
|
500 ×(105+135)×100
|
40
|
|
CZD-5
|
380 ×120 ×65
|
20
|
|
CZD-6
|
1000 ×(115+135)×130
|
45
|
|
CZD-7
|
750 ×(115+135)×130
|
35
|
|
CZD-8
|
500 ×(115+135)×130
|
23
|
Corroco International Industrial Co., Ltd is a professional manufacturer and supplier of Zinc anode in China. In addition to this sacrificial Zinc anode, we also produce magnesium anode, aluminum anode, pure iron anode, and other cathodic protection devices. With powerful electrochemistry and smelting manufacturing experts and 12 years' production experience, our products have been exported to the United States, Canada, Britain, Germany, Iran, Pakistan, India, Kuwait, Dubai, Saudi Arabia, the Philippines, Malaysia, Singapore, Congo, Turkey, etc.
